Flagship Wireless Video Transmitter
The Truebond Pro delivers zero-delay 4K wireless transmission up to 500 metres with HDR10 pass-through and 10-bit colour depth. Built for cinema-grade productions, outdoor broadcasts, and stadium sports.
| Resolution | Up to 3840 × 2160 @ 60 fps |
|---|---|
| Colour Depth | 10-bit 4:2:2 |
| HDR | HDR10, HLG, Dolby Vision pass-through |
| Codec | H.265 / HEVC, H.264 (legacy) |
| Bitrate | 5 – 80 Mbps adaptive |
| Frequency | 5.1 – 5.9 GHz (DFS aware, BIS approved) |
|---|---|
| Range (LOS) | Up to 500 m |
| Latency | < 1 ms end-to-end |
| Channels | 16 selectable, auto frequency hopping |
| Encryption | AES-128 link encryption |
| Video Input | HDMI 2.0, 12G-SDI |
|---|---|
| Video Output | HDMI 2.0, 12G-SDI loop-out |
| Network | 1 GbE, Wi-Fi 6 (control) |
| USB | USB-C (PD + data), USB-A (firmware) |
| Timecode | BNC LTC in/out |
| Power Input | 7 – 17 V DC, 18 W typ. |
|---|---|
| Mounts | NP-F, V-mount, USB-PD |
| Dimensions | 112 × 78 × 28 mm |
| Weight | 240 g (TX), 280 g (RX) |
| Operating Temp | −10 °C to +50 °C |
Mounts on your camera via NP-F or cold shoe.
Connects to any HDMI/SDI monitor or encoder.
High-gain panel + omni-directional sets.
HDMI, SDI, USB-C, and Pelican-style hard case.
